Subnanosecond-electromagnetic-pulse-generated-by-a-long-spark-discharge:-Lightning-implication-data
Creators
Description
Data description
The data is used in the paper "Subnanosecond electromagnetic pulse generated by a long spark discharge: Lightning implication" (M. Gushchin et. al.) submitted in December 2023 in Geophysical Research Letters. Two types of files are presented. First are photos stored in "png" format. Second are waveforms stored in text files. First column is time and second is value. The delimiter is ";".
Data is used in second figure
Figure_2a.png -- Photo of the the appearance and growth of leaders with their streamer zones from the upper (HV) electrode
Figure_2b.png – First flash on the lower (grounded) electrode.
Figure_2c.png -- Common streamer zone formation after the upward leader starts.
Figure_2d.png -- Current increase in downward and upward leader channels, reduction in the size of the common streamer zone.
Figure_2e.png -- Discharge main stage.
Figure_2f_curve_1.dat -- Voltage waveform from the capacitive probe corresponds to "Figure_2a.png" photo. Time unit is mks, value unit is a.u.
Figure_2f_curve_2.dat -- Voltage waveform from the capacitive probe corresponds to "Figure_2b.png" photo. Time unit is mks, value unit is a.u.
Figure_2f_curve_3.dat -- Voltage waveform from the capacitive probe corresponds to "Figure_2c.png" photo. Time unit is mks, value unit is a.u.
Figure_2f_curve_4.dat -- Voltage waveform from the capacitive probe corresponds to "Figure_2e.png" photo. Time unit is mks, value unit is a.u.
Figure_2f_curve_5.dat -- Voltage waveform from the capacitive probe corresponds to "Figure_2f.png" photo. Time unit is mks, value unit is a.u.
Data is used in third figure
Figure_3b_curve1.dat -- The power waveform from RF analyzer f0 = 6 GHz, df = 40 MHz. Time unit is mks, value unit is dB.
Figure_3b_curve2.dat -- The power waveform from RF analyzer f0 = 5.5 GHz, df = 40 MHz. Time unit is mks, value unit is dB.
Figure_3b_curve3.dat -- The power waveform from RF analyzer f0 = 4.5 GHz, df = 40 MHz. Time unit is mks, value unit is dB.
Figure_3b_curve4.dat -- The power waveform from RF analyzer f0 = 3.5 GHz, df = 40 MHz. Time unit is mks, value unit is dB.
Figure_3b_curve5.dat -- The power waveform from RF analyzer f0 = 2 GHz, df = 40 MHz. Time unit is mks, value unit is dB.
Figure_3b_curve6.dat -- The power waveform from RF analyzer f0 = 1 GHz, df = 40 MHz. Time unit is mks, value unit is dB.
Figure_3a_curve1.dat -- The voltage pulse waveforms from a capacitive probe corresponds to "Figure_3b_curve1.dat" waveform. Time unit is mks, value unit is a.u.
Figure_3a_curve2.dat -- The voltage pulse waveforms from a capacitive probe corresponds to "Figure_3b_curve2.dat" waveform. Time unit is mks, value unit is a.u.
Figure_3a_curve3.dat -- The voltage pulse waveforms from a capacitive probe corresponds to "Figure_3b_curve3.dat" waveform. Time unit is mks, value unit is a.u.
Figure_3a_curve4.dat -- The voltage pulse waveforms from a capacitive probe corresponds to "Figure_3b_curve4.dat" waveform. Time unit is mks, value unit is a.u.
Figure_3a_curve5.dat -- The voltage pulse waveforms from a capacitive probe corresponds to "Figure_3b_curve5.dat" waveform. Time unit is mks, value unit is a.u.
Figure_3a_curve6.dat -- The voltage pulse waveforms from a capacitive probe corresponds to "Figure_3b_curve6.dat" waveform. Time unit is mks, value unit is a.u.
Figure_3c.dat -- Waveform obtained using TEMH. Time unit is mks, value unit is V/m.
Figure_3d.dat – Detailed waveform obtained using TEMH. Time unit is ns, value unit is V/m.
Data is used in fourth figure
Figure_4b_curve_1.dat – TPMP waveform obtained during calibration. Time unit is ns, value unit is A/m.
Figure_4b_curve_2.dat – IPPL waveform obtained during calibration. Time unit is ns, value unit is E/m.
Figure_4c_curve_1.dat – TEMH waveform obtained in shot #104 at 12-oct-22. Time unit is ns, value unit is E/m.
Figure_4c_curve_2.dat – IPPL waveform obtained in shot #104 at 12-oct-22. Time unit is ns, value unit is E/m.
Figure_4d_curve_1.dat – TEMH waveform obtained in shot #19 at 13-oct-22. Time unit is ns, value unit is E/m.
Figure_4d_curve_2.dat – IPPL waveform obtained in shot #19 at 13-oct-22. Time unit is ns, value unit is E/m.
Figure_4e_curve_1.dat – TPMP waveform obtained in shot #19 at 25-sept-23. Time unit is ns, value unit is A/m.
Figure_4e_curve_2.dat – IPPL waveform obtained in shot #19 at 25-sept-23. Time unit is ns, value unit is E/m.
Figure_4f_curve_1.dat – TPMP waveform obtained in shot #2 at 27-sept-23. Time unit is ns, value unit is A/m.
Figure_4f_curve_2.dat – IPPL waveform obtained in shot #2 at 27-sept-23. Time unit is ns, value unit is E/m.
Data is used in fifth figure.
Figure_5a.png – The photo of negative discharge
Figure_5b.dat -- Waveform from a capacitive probe. Time units is mks, value units is a.u.
Figure_5c.dat -- The power waveform from RF analyzer f0 = 0.98 GHz, df = 40 MHz obtained simultaneously with Figure_5b.dat. Time unit is mks, value unit is dB.
Figure_5d.dat -- UWB EMP waveform obtained using TEMH obtained simultaneously with Figure_5c.dat. Time unit is ns, value unit is V/m.
