FIGURE 3A–D in Two new species of Lepidocyrtus (Fractocyrtus) Cipola & Bellini (Collembola Entomobryidae, Lepidocyrtinae), with new records and a new name for Lepidocyrtus (F.) americanus Cipola & Bellini, 2018
- 1. Laboratório de Sistemática e Ecologia de Invertebrados do Solo, Instituto Nacional de Pesquisas da Amazônia - INPA, CPEN. Avenida André Araújo, 2936, Aleixo, 69067-375, Manaus, AM, Brazil. & Corresponding Author: Nikolas Gioia Cipola: nikolasgc@gmail.com; https://orcid.org/0000-0002-7594-9574
- 2. Laboratório de Sistemática e Ecologia de Invertebrados do Solo, Instituto Nacional de Pesquisas da Amazônia - INPA, CPEN. Avenida André Araújo, 2936, Aleixo, 69067-375, Manaus, AM, Brazil.
Description
FIGURE 3A–D. Lepidocyrtus (F.) amazonaensis nom. nov., SEM images; A, anterior head, pl1–2 are prelabral chaetae, a1–2, m0–2 and p0–2 labral chaetae, b.c. and t.a. of the maxillary palp, sb. appendages of sublobal plate and A, B, D and E labial papillae (papilla C omitted); B, distal tibiotarsus and empodial complex III (posterior view), b.t., m.t. and a.t. is unguis inner teeth, red arrow indicates lateral tooth, white arrow is unguiculus lamellae; C, distal manubrium and proximal dens (dorsal view), white arrow indicates chaetae of manubrial plate and red arrow dental tubercle; D, dens dorsal spine. Scale bar: A and C (0.02 mm), C (0.01 mm), D (0.005).
Notes
Published as part of Cipola, Nikolas Gioia & Viana, Stéphanie Dos Santos, 2023, Two new species of Lepidocyrtus (Fractocyrtus) Cipola & Bellini (Collembola Entomobryidae, Lepidocyrtinae), with new records and a new name for Lepidocyrtus (F.) americanus Cipola & Bellini, 2018, pp. 369-399 in Zootaxa 5369 (3) on page 374, DOI: 10.11646/zootaxa.5369.3.3, http://zenodo.org/record/10151336
