Quantum-Inspired Thermal Equilibrium: Integration of Collective Dynamics into Real-Time Stabilization of Magnetically Confined Fusion Plasmas — Extended Edition with Adversarial Stress Benchmark on TORAX 1.4 (Full ITER Pulse, Extended Severity Sweep up to ×1800 ITER Worst-Case, Hardware-in-the-Loop Demonstration on STM32F411 Microcontroller, and Single-Seed 500 000 s Long-Pulse Observation

2026-06-25 — Hardware-in-the-loop extension of the IterHybrid-XHARD adversarial control-theory stress benchmark. The same controller, same plant, same disturbance cascade are re-run with the 8-bit quantised QITE collapse kernel transplanted onto a physical 5 EUR STM32F411 Cortex-M4 microcontroller (WeAct Black Pill V3.x) connected to the host TORAX 1.4 runner (Citrin et al., 2024) over USB-CDC ACM at VID 0483 / PID 5740. The host evaluates the SDK observe() pass locally; the converged per-agent sufficient statistics (6 bytes per agent, 30 bytes per 5-actuator fleet) are shipped to the chip every control tick, and the chip returns 5 signed-int16 deltas (10 bytes) per tick. Round-trip latency p50 = 213 µs, p99 = 300 µs; per-tick kernel ~ 1.58 ns on x86_64 reference, ~ a few hundred ns on Cortex-M4. Bit-identity against the host x86_64 reference is verified over 100 000 random inputs (0 mismatches). Over 200 seeds at XHARD severity 5.0 with 1 200 s episodes, the hardware survival rate is 137 / 200 = 68.5 % [Wilson 95 % CI: 61.8 %, 74.5 %], statistically equivalent to the host x86_64 implementation of the same kernel (67 / 100 = 67.0 %) and to the FP32 reference policy (63 / 100 = 63.0 %) — bit-equivalence is preserved end-to-end from FP32 reference through Q8 host quantization to the physical Cortex-M4 silicon. A complementary extended severity sweep covers 23 disturbance-amplitude levels from XHARD sev = 1.5 to sev = 40 (the latter corresponding to up to ~ ×1800 documented ITER worst-case projection levels along the saturating disturbance channels, Snipes 2017), 100 seeds × 3 policies × 23 sev = 6 900 episodes total; the deterministic five-agent QITE policy survives 90 / 100 at sev = 1.5, 63 / 100 at sev = 5.0, 47 / 100 at sev = 10, and 6 / 100 at sev = 40, mapping the closed-loop failure envelope of the controller across two and a half orders of magnitude of disturbance amplitude. A single-seed exploratory long-pulse run on the same chip at sev = 5.0 (seed 0, t_final raised from 1 200 s to 499 999 s ≈ 5.79 days simulated, ≈ 416 × a standard ITER Hybrid pulse duration) completed without disruption at Q_fus mean = 5.155, H98 mean = 1.884, β_N max = 1.658 (vs Troyon hard limit 3.0, Troyon 1984), q_min min = 0.502 (vs sawtooth threshold 0.5, La Haye 2006), absorbing 325 494 stacked adversarial events (100 000 ELM, 108 546 ECRH dropouts, 116 948 NBI dropouts) and traversing 1 489 closed H-mode → back-transition → L-mode reset → H-mode cycles with mean period 335.6 s and no observable drift in rolling 10 000-tick means of Q, q_min, β_N or H98 across the run. The single-seed long-pulse observation is not statistically validated (N = 1) and is reported for completeness; under the working assumption that per-tick disruption probability is constant — the natural inference from the 200-seed 1 200 s pulse-survival rate — the probability of 416 sequential 1 200 s windows surviving without disruption would be 0.685^416 ≈ 10⁻⁶⁷, a discrepancy consistent with disruption probability being concentrated in transient phases (ramp-up, L→H transitions, recovery from deep resets) rather than uniformly distributed in time. No formal model is proposed. The aggregate deposit now contains 10 500 reproducible episodes across 17 (date × study × policy) groups, 8 157 per-tick CSV log files (~ 2.48 million individual plasma snapshots covering T_e, T_i, n_e, β_N, q95, q_min, Q_fus, H98, f_BS, f_GW per tick), the master episode index, four cross-study comparison figures, the consolidated 108-page master deposit document (all A4) with all measurement-paper writeups embedded inline with bookmark navigation, the device-under-test photograph, the full XHARD scenario specification and configuration metadata, and an 18-figure visualisation suite of the long-pulse observation (full trajectory, state-space attractor projections, cycle-period analysis, drift check, safety-margin time series, power spectrum of q_min, marginal histograms). All measurement data and figures released under CC-BY-4.0 / CC0; only the QITE Core SDK itself remains proprietary (DPMA Aktenzeichen 10 2025 003 906.9 and 10 2025 004 891.2). No engine internals are required to reproduce any reported number from the included CSV logs. Full technical specification of the consolidated 108-page master deposit document.

2026-06-12 — Full ITER pulse update of the IterHybrid-XHARD adversarial control-theory stress benchmark. The same controller, the same plant, the same disturbance cascade are re-run at 1200 s of plasma flat-top — the full ITER pulse duration target (van Mulders 2021), eight times longer than the 2026-06-07 block. The only configuration difference is --t-final 1200 passed to the TORAX 1.4 runner (Citrin et al., 2024); the disturbance probabilities per control tick, the per-actuator lambda mappings, the random seeds, and the QITE Core SDK build remain byte-identical. Over 300 reproducible episodes (3 policies × 100 actuator-noise seeds), the deterministic five-agent QITE controller delivers 88 / 100 disruption-free episodes — bit-identical to the survival rate of the 150 s block — at Q_fus = 6.02 ± 1.80 in H-mode confinement (H98 = 1.88 ± 0.31), absorbing 691.6 ± 243.6 stacked adversarial events per episode (a factor of 7.6 more than the 150 s block, scaling linearly with pulse duration). Pairwise safety margins (β_N max = 1.46 ± 0.10 vs the 3.0 Troyon hard limit, q_min min = 0.52 ± 0.03 vs the 0.5 sawtooth threshold, La Haye 2006) are statistically indistinguishable from the 150 s block. The Q_mean drop from 7.94 to 6.02 across the eight-fold longer flat-top is the expected physical consequence of cumulative current-profile drift between disturbance recovery cycles; both Q values sit clearly in the burning regime (Q > 5 in the Hybrid envelope of van Mulders 2021). The open-loop reference again 'survives' 100 / 100 only by saturating in L-mode at Q = 3.61 (H98 = 0.80); the uniform-random baseline disrupts in 100 / 100 attempts. By the standard engineering stress-margin inference, the controller's survival of the IterHybrid-XHARD cascade — calibrated at one to two orders of magnitude above documented ITER worst-case projections (Snipes 2017) — over the full ITER pulse duration plausibly supports survival at nominal 1× conditions with a much larger margin. This is not a formal hardware-deployment proof; real-tokamak validation remains out of scope. The 1200 s block is published as a second data folder (1200s_full_iter_pulse/) alongside the existing 150 s block, under CC-BY-4.0 / CC0. The original 150 s data and figures from the 2026-06-07 version remain accessible via the version history of this Zenodo record. Full technical specification of the 9-page extension paper.

2026-06-07 — Adversarial control-theory stress benchmark of the QITE multi-agent plasma controller on the native Google DeepMind TORAX 1.4 step-level API (Citrin et al., 2024) under the deliberately exaggerated IterHybrid-XHARD disturbance cascade. The benchmark imposes seven simultaneously active stochastic disturbance processes on the ITER Hybrid scenario at 12 MA / 5.3 T (Polevoi 2005, van Mulders 2021), each calibrated above its real-ITER analogue by between one and two orders of magnitude: ELM crashes every 5 s with a 15 % radiation spike, NBI dropouts at 20 % per control tick, ECRH dropouts at 15 % per tick, Z_eff random walk with σ = 0.15 s⁻¹, gas-puff flow noise five times nominal, actuator command noise σ = 5 %, actuator slew rates halved relative to the ITER emergency-mode envelope (Snipes 2017 §5 Tab 3). Over 300 reproducible episodes (3 policies × 100 actuator-noise seeds), the deterministic five-agent QITE controller — implementing the ITER PCS Tier-1 hierarchy (Ip, NBI, ECRH, gas puff) plus the Tier-2 Disruption Mitigation System via the Mavrin impurity-radiation proxy (Lehnen 2015 §4, Hollmann 2015) — delivers 88 / 100 disruption-free episodes at the physically-correct Hybrid operating point Q_fus = 7.94 ± 1.26 in H-mode confinement (H98 = 2.13 ± 0.40), absorbing 90.5 ± 20.7 stacked adversarial events per episode. The open-loop reference 'survives' 100 / 100 only by saturating in L-mode at Q = 3.60 ± 0.00 (H98 = 0.80 ± 0.00); the uniform-random baseline disrupts in 100 / 100 attempts at Q = 23.32 ± 13.55. A Welch two-sample t-test on Q_mean of survivors yields p = 1.06 × 10⁻⁹⁸ against the open-loop reference, and Fisher exact on survival counts yields p < 10⁻³⁰ against the random baseline — the QITE distribution is statistically separated from every baseline at p < 10⁻¹³. Operating-point trajectories sit with substantial safety margin both below the Troyon no-wall β_N limit (β_N max = 1.41 ± 0.09 vs 3.0 hard limit) and above the sawtooth + 2/1 NTM lock threshold on q_min (La Haye 2006); the architectural advantage is shown to come from the Tier-1 + Tier-2 actuator hierarchy and the shared emergent collective field, not from threshold tuning specific to the adversarial scenario — the controller configuration is the off-the-shelf five-agent QITE emergency-mode setup with the cited per-actuator lambda mapping, applied without modification. The complete adversarial-benchmark deposit — 300 per-tick CSV logs of all episodes, configuration and run metadata, aggregate statistics, headline statistical tests, nine reproduced figures, and full disturbance-cascade and scenario specification — is published openly under CC-BY-4.0 / CC0; only the QITE Core SDK itself remains proprietary, and no engine internals are required to reproduce any reported number from the included CSV logs. Full technical specification of the 9-page benchmark paper.

External validation of the QITE multi-agent plasma controller against the third-party Google DeepMind TORAX simulator (Citrin et al., 2024) via the gymtorax 1.0.0 reinforcement-learning wrapper (Mouchamps et al., 2026). Over 30 reproducible episodes on gymtorax/IterHybrid-v0 (3 policies × 10 seeds, ITER-hardware-realistic actuator noise σ = 0.5 % per Hemsworth 2017, Henderson 2020, Mitchell 2008) the QITE policy delivers a mean end-of-scenario fusion gain of Q = 8.57 ± 6.34, against Q = 7.69 ± 0.03 for the open-loop IterHybridAgent reference and Q = 2.22 ± 0.79 for a uniform-random baseline — +11.5 % above the reference at simultaneously 36 % larger Troyon-limit margin (β_N = 1.25 vs 1.94) and factor 2.7 larger sawtooth-onset margin (q_min = 1.70 vs 0.625). No disruptions occurred for any policy across the 30 episodes. The QITE engines sustained 4.21 × 10⁹ decisions per second across 5.285 × 10¹¹ total decisions in 445 seconds wall time. A previously unobserved bimodal operating-point behaviour of the closed-loop QITE controller is documented and discussed. The complete external-validation deposit — application source, per-step CSV logs of all 30 episodes, aggregate statistics, and tick-by-tick replay animations — is published openly under MIT / CC-BY-4.0 / CC0; only the QITE Core SDK itself remains proprietary. Full technical specification of the 22-page companion paper

Interdisciplinary treatise on the mathematical, physical, and information-theoretic foundations of the QITE formalism and its application to the real-time stabilization of magnetically confined fusion plasmas. 258 pages, 20 chapters, 4 appendices. Topics: spectral theory, Lyapunov stability, Grad–Shafranov equilibrium, MHD stability theory, neoclassical and anomalous transport, disruption avoidance, zero-allocation C++17 implementation, CUDA parallelization, ITER baseline simulation with 1,536 coupled QITE engines on a 128×192 grid. Validation against the IPB98(y,2) scaling law, the Greenwald density limit, and experimental data (JET, DIII-D). German patent applications Az. 10 2025 003 906.9 and Az. 10 2025 004 891.2.

The deposit additionally includes the executable reference implementation tokamak_sim in two prebuilt variants — tokamak_sim.exe (CPU, MSVC x64) and tokamak_sim_cuda.exe (CUDA 13.1, GPU-accelerated 1,536-engine sensor swarm at ~10⁹ QITE decisions per second) — together with full source (C++17 + CUDA), CMake/MSVC build scripts, and a 22-page companion paper (Simulation.pdf) extending the main treatise. The simulation environment couples the deterministic plasma physics layer (Bosch–Hale D-T reactivity, Modified Rutherford NTM dynamics, peeling-ballooning ELMs, Putterich impurity radiation, Sauter bootstrap current, Connor–Hastie runaway model) to a three-tier control hierarchy: a 1,536-engine QITE sensor swarm (treatise §7.2), a six-engine actuator-agent layer (NBI, ECRH, ICRH, gas-puffing, vertical PF coils, shattered-pellet injection — companion §3) governing all physical actuators autonomously through their individual coherence dynamics, and a parallel six-mechanism stochastic perturbation channel (ELM Poisson process, NTM onset roulette, Brownian vertical drift, NBI source glitches, sensor noise, locked-mode onset — companion §4) reproducing the operationally relevant statistical character of a real tokamak plasma. Empirical validation over a 390 s flat-top run (default seed 0xC0FFEE, severity σ=1.0, all stochastic mechanisms active, no operator interventions) reproduces the steady-state envelope of treatise §11.10 essentially exactly: disruption risk 26.7 % ± 4.7 %, no excursion above 32 %, zero terminal disruptions, mean fusion power 488 MW (within 2.4 % of the ITER design point of 500 MW), β_N=1.73, and a saturated (2,1)-NTM amplitude of 0.201, consistent with stochastically driven flat-top operation. Full bit-identical replication is supported through fixed-seed semantics and the run metadata persisted in every CSV log header.
